Axial fan built on an external-rotor motor platform. High airflow at low static pressure — ideal for ventilation, condenser and cooling applications.
Technical Specifications
| Model Code | Curve | Voltage (V) | Frequency (Hz) | Speed (rpm) | Power (W) | Current (A) | Noise (dB) | Temp (°C) |
|---|---|---|---|---|---|---|---|---|
| A3P350-EC072-012 | ① | 220 | 50/60 | 1380 | 90 | 0.65 | 57 | -25～+60 |
| A3P350-EC072-013 | ① | 220 | 50/60 | 1380 | 90 | 0.65 | 57 | -25~+60 |
| A3P350-EC092-04* | ① | 220 | 50/60 | 1550 | 165 | 1.1 | 67 | -25～+60 |
