The fan is composed of external rotor asynchronous motor, plastic/aluminum impeller, etc. The motor has low temperature rise and has special advantages of ventilation, heat dissipation, self-cooling, etc. Thus, the reliability of fan service life is extended. The fan is a backward curved impeller, which has the characteristics of compact structure, large air volume, high static pressure, small vib
Technical Specifications
| Model Code | Curve | Voltage (V) | Frequency (Hz) | Speed (rpm) | Power (W) | Current (A) | Noise (dB) | Temp (°C) |
|---|---|---|---|---|---|---|---|---|
| B3P133-EC072-028 | ① | 220 | 50/60 | 4500 | 55 | 0.4 | 64 | -25~+60 |
| B3P133-EC072-100 | ① | 220 | 50/60 | 4500 | 45 | 0.32 | 68 | -25～+60 |
| B3P133-EC072-010 | ① | 220 | 50/60 | 4500 | 45 | 0.32 | 68 | -25~+60 |
| B3P133-EC072-060 | ① | 220 | 50/60 | 4500 | 45 | 0.32 | 68 | -25～+60 |
| B3P133-EC072-061 | ① | 220 | 50/60 | 4500 | 45 | 0.32 | 68 | -25~+60 |
| B3P133-EC072-101 | ① | 220 | 50/60 | 4500 | 50 | 0.4 | 69 | -25~+60 |
| F3P133-EC072-618 | ① | 220 | 50/60 | 1700 | 45 | 0.3 | 65 | -25～+60 |
| F3P133-EC072-002 | ② | 220 | 50/60 | 2100 | 65 | 0.5 | 71 | -25～+60 |
| F3P133-EC072-050 | ① | 220 | 50/60 | 1500 | 80 | 0.6 | 59 | -25～+60 |
| F3P133-EC072-016 | ① | 220 | 50/60 | 1500 | 80 | 0.6 | 59 | -25~+60 |
| F3P133-EC092-100 | ① | 220 | 50/60 | 1700 | 115 | 0.8 | 60 | -25~+60 |
