The fan is composed of external rotor asynchronous motor, plastic/aluminum impeller, etc. The motor has low temperature rise and has special advantages of ventilation, heat dissipation, self-cooling, etc. Thus, the reliability of fan service life is extended. The fan is a backward curved impeller, which has the characteristics of compact structure, large air volume, high static pressure, small vib
Technical Specifications
| Model Code | Curve | Voltage (V) | Frequency (Hz) | Speed (rpm) | Power (W) | Current (A) | Noise (dB) | Temp (°C) |
|---|---|---|---|---|---|---|---|---|
| F3P146-EC092-035 | ① | 220 | 50/60 | 1300 | 80 | 0.6 | 61 | -25～+60 |
| F3P146-EC092-057 | ① | 220 | 50/60 | 1700 | 165 | 1.1 | 65 | -25～+60 |
