The fan is composed of external rotor asynchronous motor, plastic/aluminum impeller, etc. The motor has low temperature rise and has special advantages of ventilation, heat dissipation, self-cooling, etc. Thus, the reliability of fan service life is extended. The fan is a backward curved impeller, which has the characteristics of compact structure, large air volume, high static pressure, small vib
Technical Specifications
| Model Code | Curve | Voltage (V) | Frequency (Hz) | Speed (rpm) | Power (W) | Current (A) | Noise (dB) | Temp (°C) |
|---|---|---|---|---|---|---|---|---|
| F3P160-EC072-100 | ① | 220 | 50/60 | 1500 | 80 | 0.6 | 52 | -25～+60 |
| F3P160-EC072-900 | ① | 220 | 50/60 | 1900 | 120 | 0.86 | 65 | -25~+60 |
| F3P160-EC072-901 | ① | 220 | 50/60 | 1750 | 100 | 0.72 | 64 | -25~+60 |
| F3P160-EC092-637 | ① | 220 | 50/60 | 1900 | 110 | 0.75 | 66 | -25～+60 |
| F3P160-EC092-100 | ② | 220 | 50/60 | 2150 | 150 | 1.0 | 67 | -25～+60 |
| F3P160-EC092-064 | ① | 220 | 50/60 | 1150 | 120 | 0.9 | 60 | -20~+40 |
| F3P160-EC092-900 | ① | 220 | 50/60 | 1500 | 260 | 1.5 | 70 | -20~+40 |
